First thoughts on the new Sony PXW-X70

Categories: Miscellaneous 4 Comments

x70-front

  • 4K ready 1.0 type Exmor R CMOS sensor for a wide range of shooting conditions

    The PXW-X70 incorporates a 4K-ready 1.0 type Exmor R CMOS sensor to achieve high resolution, high sensitivity, low noise, and wide dynamic range. The sensor has 14,2 million effective pixels enhancing shooting under severe lighting conditions and providing more freedom of creative expression.

  • High sensitivity and high resolution

    Thanks to the 1.0 Exmor R CMOS sensor, the PXW-X70 has high sensitivity 1.67 stops brighter than a 1/2.88-inch sensor. The camcorder also has higher resolution than any other camcorder in its price range. The 1.0 sensor is brighter and offers more bokeh with a shallow depth of field than 1/3-inch or 1/4.7-inch sensors.

  • Advanced BIONZ X image processing engine

    An evolved BIONZ engine achieves more lifelike images, and enables the addition of new features that take advantage of faster processing.

  • Compact body

    The palm-sized PXW-X70 is ergonomically designed to provide a lightweight and easy-to-use experience.

x70-side

  • Wi-Fi/NFC (Near Field Communication) with Content Browser Mobile™

    The PXW-X70 can be remotely controlled from a smartphone or tablet computer (iOS 4.3 through 7.0 or Android 2.3 through 4.3) via a Wi-Fi connection, and recorded video files can be transferred from camcorder to smartphone in MP4 format.* One-touch authentication is also possible with smartphones that offer NFC connectivity. The required Content Browser Mobile™ mobile smartphone application can be downloaded from the Google Play Store or App Store.

    * Wi-Fi operation cannot be guaranteed with all smartphones and tablet computers.

  • Multi-format recording and 4K ready

    The PXW-X70 records XAVC Long GOP 422 10-bit 1920 x 1080 50p/60p/50i/60i/ 30p/25p/24p at 50 Mbps and 35 Mbps, 1920 x 1080 50i/60i at 25 Mbps, as well as 1280 x720 50p/60p at 50 Mbps. It is also possible to record AVCHD 420 8-bit at 1920 x 1080 and 1280 x720 and DV. The PXW-X70 is also 4K ready and can handle 4K recordings with a future upgrade.

  • Dual media slots, “Simul” or “Relay” recording, and independent record control

    The PXW-X70 is equipped with two memory card slots. The camcorder is compatible with Memory Stick PRO Duo (Mark 2), Memory Stick PRO-HG Duo and Memory Stick XC-HG Duo media, as well as SDXC and SDHC cards. Two media slots can record in either “Simul” or “Relay” mode. “Simul” mode permits simultaneous recording to two memory cards, while “Relay” mode automatically switches recording from the first to the second memory card when the first is full. The user can set up the two Start/Stop buttons on the PXW-X70, one on the grip and one on the camcorder body, to independently start and stop recording on different memory cards while recording in Simul mode.

  • ND filter control mechanism

    The PXW-X70 is equipped with a variable ND Filter function, allowing you to choose four conventional mechanical ND filter positions from 1/4ND, 1/16 to 1/64ND.

pxwx70_side_one

  • ZEISS Vario-Sonnar T* lens

    The PXW-X70 is supplied with a fixed 29 mm wide-angle ZEISS Vario-Sonnar T* lens. Ideal for capturing grand landscapes, it also provides up to 12x optical zoom.

  • Clear Image Zoom

    The 12x optical zoom can be doubled to 24x with Clear Image Zoom, maintaining full resolution using Super Resolution Technology. In addition, Digital Extender can double this range again, up to 48x zoom. Super Resolution Technology is a Sony original intelligent interpolation which analyses the input image and increases the resolution of the image.

  • Lens ring

    The lens ring enables smooth, natural adjustment of focusing or zooming, depending on which mode is selected.

  • Manual controls

    The manual dial and buttons on the side of the body allow swift and easy adjustment of IRIS (aperture), GAIN/ISO and shutter speed.

  • Slow & Quick Motion

    Smooth slow or quick motion with full HD quality is available without any extra processing. 2x slow motion can be easily achieved by setting the recording format to 25p and the frame rate to 50 fps. The frame rate can also be set to 1 fps for 50x quick motion. In order to go into the S&Q Motion mode, the camera needs to be in XAVC & AVCHD mode (Not DV mode) and Manual mode.

  • Picture Profile

    You can fine-tune the look of movies before shooting by adjusting gradation (black level, gamma and black gamma), adjustment ( mode, intensity, tone and depth), basic (gamma and mode) and more. Adjusted parameters can be saved along with other settings as a profile, and up to seven profiles can be stored for later recall.

  • 99 Camera Profiles

    It is possible to save up to 99 camera settings under different profile numbers. User can copy the settings from one PXW-X70 to another PXW-X70 so that user can shoot with multiple cameras in the same settings (only works with same model camcorders). Also, users can save camera settings for each scene, so that it is possible to recall proper settings for the scene immediately.

pxwx70_rear

  • Multi Interface Shoe (MI Shoe) for flexible connection without XLR cable

    The MI Shoe* on top of the PXW-X70 has several possibilities to be used to attach the supplied handle, which will allow Rec Start/Stop, Zoom & Audio Control. Using the MI Shoe connection and the optional adapter SMAD-P3, the audio signal from a UWP-D11 or UWP-D12 wireless microphone package can be input from the wireless microphone receiver to the PXW-X70 without an XLR cable. The power can be supplied from the PXW-X70 to the receiver and a battery is not required for the receiver operation.

    * It is not recommended to use the HVL-LBPC light with the MI Shoe as the battery requirement is too high. When the handle is attached to the MI Shoe, it is not possible to use the MI Shoe to control the DWZ-D receiver.

  • Viewfinder includes amazing OLED technology

    This 0.39-inch OLED viewfinder offers superb OLED brightness, contrast and response. The high resolution (1,440K dot) of the viewfinder allows better precision of manual focus operations and eliminates any colour-breaking phenomenon.

  • High resolution LCD

    The PXW-X70 incorporates a 3.5-inch 1,555K dot LCD, offering high resolution and flexible composition options.

  • Wide choice of connections

    The camcorder offers numerous connections to suit the broadcast workflow, including 3G HD-SDI, HDMI®, USB and composite output. The Rec Trigger signal can be sent through SDI and HDMI to link an external recording device.

pxwx70_rear-side

HDW : Not since the NX70 has Sony produced a camera that excites me more than the X70. Finally Sony have been listening even down to the dual screw knobs on the handle itself.

1080 50p at 50Mbps 422 10bit should by all accounts produce a stunning picture, more importantly one that is “Broadcast” spec in a hand held format. For those of us using NX30’s it’s a blessing that Sony have adopted the L-Ion “V” battery pack not to mention the ND filters a feature missing on both the NX30 and NX70 camcorders.

Coming from a 4K ready 1″ sensor hopefully means very little noise at 0dB and lets hope a smooth variable zoom from day one.

This camera is seriously tempting for the majority of work I do and for £2300 its a snip for a 10bit 422 camcorder.

Sony have promised me a camera for review lets hope it comes before the winter sets in !

For all your video production needs in Scotland, get in touch with Small Video Company Ltd

BBC R&D at the Commonwealth Games 2014

Categories: Miscellaneous 2 Comments

4K

I got an invite on Monday to see the BBC R&D team at the Glasgow Science Centre as they were experimenting with 4K.

show

IP-switcher

wall-v2

Brandon

My thanks to Brandon Butterworth for the invite, here is a small 5m film I made…enjoy

For all your video production needs in Scotland, get in touch with Small Video Company Ltd

NEW Sony PXW-X70 camcorder (Approx £2000 plus vat) end of September

Categories: Miscellaneous 5 Comments

Sony-pxwx70

Sony has today launched the 4K-ready PXW-X70, the first compact XDCAM professional camcorder ever produced. Expanding the popular file-based XDCAM family to a new smaller form factor and lower price point, Sony has combined stunning picture quality, speed of shooting and robust performance into a package which is ideal for a wide range of applications from news gathering and documentary to events work.

The PXW-X70 features a 1.0 type Exmor® R CMOS Sensor with a resolution of 20 megapixels. The sensor, which is even larger than the Super 16mm film frame, delivers high resolution and fantastic low light performance, as well as offering more depth of field control as demanded by today’s diverse shooting requirements. The new camcorder has the ability to record High Definition in XAVC Long GOP, enabling 422 10-bit sampling at 50 Mbit/s. This in-turn supports a broadcast-quality workflow, increasingly adopted by productions in many different professional applications.

This addition to the expanding next generation XDCAM family follows the recently announced PXW-X180 and PXW-X160 and builds upon Sony’s successful heritage of compact professional camcorders. The PXW-X70 is the first professional compact camcorder from Sony to include Wi-Fi-enabled control via Smart Phone or Tablet using the Content Browser Mobile application. An upcoming release will also provide customers with the ability to upgrade the PXW-X70 to record in 4K Ultra High Definition, with file transferring, and live video streaming capabilities.

“This first compact member of the XDCAM family brings the performance and workflow benefits associated with XAVC to an even wider range of shooting scenarios,” said Robbie Fleming, Product Marketing Manager, at Sony Professional Solutions Europe. “Over the past couple of years we’ve seen the broadcast industry really embrace the picture quality benefits associated with large sensors; the one-inch sensor at the heart of the PXW-X70 sets a new standard for colour, depth and texture in a professional compact camcorder. Coupled with the ability to upgrade to 4K, this represents a multipurpose, future-proof option for customers looking for a tough camcorder which doesn’t compromise on image.”

Key features of the PXW-X70

  • 1.0 type Exmor® R CMOS Sensor and Carl Zeiss Vario Sonnar T* lens for stunning picture quality. High sensitivity and fantastic resolution with 14.2 million effective pixels delivers striking detail and colours, even in low light conditions. The lens offers a 12x Optical Zoom, which can be increased to 24x with Clear Image Zoom while retaining full resolution thanks to Super Resolution Technology. Zoom performance can be doubled at any point with a Digital Extender by up to 48x.
  • Compact, lightweight XDCAM camcorder packed with adaptable professional functions. The PXW-X70 weighs less than 1.4kg, including the XLR handle unit, battery (NP-FV70), lens hood and large eye-cup. It offers professional interfaces such as 3G-SDI and HDMI output connectors plus an XLR x 2 handle unit with zoom lever. Other professional features include a manual lens ring that can intuitively control zoom and focus, ergonomic palm grip with large zoom lever, two SD memory card slots for backup, simultaneous and relay recording, and a three-level switchable ND filter.
  • Breadth of recording format capabilities. Provides multiple choices depending on application required, including XAVC, AVCHD and DV® file-based recording. When recording in XAVC, the PXW-X70 uses the MXF file format, efficiently compressing full HD (1920 x 1080) resolution using the MPEG-4 AVC/H.264 CODEC. Image sampling is 4:2:2 10-bit with high-efficiency Long-GOP compression at 50 Mbps, 35 Mbps or 25 Mbps.
  • Built-in Wi-Fi control functionality for monitoring and remote control versatility. Near Field Communication functions enable easy, one-touch wireless LAN connection to a smartphone or tablet, while the Content Browser Mobile application allows confirmation of shot angles and operation of the camcorder by remote, including field angle setting, spot focus and iris adjustment.
  • Upcoming announcements to add even greater, future-proof functionality. Sony is set to make upgrades to 4K and file transfer and streaming by Wi-Fi function available for the PXW-X70 in the coming months.

For all your video production needs in Scotland, get in touch with Small Video Company Ltd

BBC R&D evening plus Marti Pellow from Wet Wet Wet

Categories: Miscellaneous No Comments

BBC-R&D

Watching the Commonwealth Games on a 4K TV is breath taking especially one thats the size of your living room wall…full report tomorrow.

Marti

Coming out of the Science Centre I heard a familiar sound…Wet Wet Wet, wee Marti was given it Laldie as they say in Glasgow, at 49 his voice is still packing in the crowds.

Crowd

Our-Chick

Local BBC sports celebrity Chick Young was on hand to capture the ambience.

WS

Lads

Not quite sure why this was being filmed but the lads were doing a grand job.

For all your video production needs in Scotland, get in touch with Small Video Company Ltd

My wee documentary for the Barr’s Pop up Shop

Categories: Miscellaneous 1 Comment



Filming-window

I spent 3 days last week filming around the city centre of Glasgow, mainly at the Merchant city capturing the essence of the Barr’s Pop up Shop. All profits from the shop go to support a new Hospice for Glasgow.

Pop-up-shop

check-oot

Cosmopolitain

The city has never looked better, very cosmopolitan.

Filming-better

All footage was shot on my Panasonic GH4’s though I do have to admit using the YAGH with a gun mic does slow up the whole process.

1080 50p @ 200Mbps…fantastic !

Renwick-sisters

Scottish sisters Kimberley and Louise Renicks came to the Barr’s Pop up Shop to show off their well earned gold medals.

Here is my wee documentary…enjoy.

For all your video production needs in Scotland, get in touch with Small Video Company Ltd

CAMBO eyecup proves popular “sold out”

Categories: Miscellaneous 1 Comment



Ecup-update

These CAMBO eyecups are proving to be very popular so much so they have temporarily sold out, they are exclusive meantime to HD Warrior and only sold via our on-line shop.

You can pre order an eyecup and I will only take your money when its back in stock. eMail hdwarrior@me.com

For all your video production needs in Scotland, get in touch with Small Video Company Ltd

“Let the games begin” GH4 pictures

Categories: Miscellaneous No Comments


Games-begin-v2

Here is a range of pictures taken with the GH4, this is a very capable photographic camera and with a speed 3 class 10 SDXC card inserted you can run 12fps for about 7 seconds…fantastic.

The picture above was caught with a 35-100mm f2.8 Lumix lens set at 100mm @ f2.8 shutter at a 30th sec at 12fps

C300-v2



David Smile Girl flag-bearer Wee-lamb CycleBaton

All the pictures above used the Lumix 35-100mm f2.8 lens with the action shots set at 12fps auto tracking.





For all your video production needs in Scotland, get in touch with Small Video Company Ltd

Glasgow a great 4m video from the “Big Yin”

Categories: Miscellaneous No Comments

Big-Yin

As Glasgow enters “Commonwealth Games Mode” the city has been transformed, this 4m video shot with Billy Connolly one of the Commonwealth ambassadors is a great tribute to a great city.

PS. If you shot this let me know , any background info and pics greatly received.

For all your video production needs in Scotland, get in touch with Small Video Company Ltd

Shocking pictures from BBC Network news

Categories: Miscellaneous 1 Comment

Dirty-lens

Working this morning I had the telly on in the background watching the live inserts for the Commonwealth Games when I noticed this 2 shot.

I suspect its from an unmanned dome camera but the perspex or camera lens was filthy, this is certainly NOT the quality of pictures you expect from the BBC.

It’s slack and poor production values that cause this type of picture to appear on mainstream television…did no one check or care that the picture was substandard or as I suspect the damage was inside the lens.

main-camIn fact looking at this again it’s the main camera you would not dare use a remote dome camera as a main live camera so the lens was dirty…shocking.

Get your act together BBC filthy lenses is a total lack of care and NOT ACCEPTABLE !!!

For all your video production needs in Scotland, get in touch with Small Video Company Ltd

GH4 User Review “the bits I left out”

Categories: Miscellaneous No Comments

GH4-bits

Video reviews can not only take a while to produce but editorially you can’t include everything, my reasons for leaving some information out like future features and flaws are this blog and making the review watchable.

I decided this time to let you see a variety of shots and situations and leave the nitty gritty to a blog post.

Flaws

Strangely the YAGH stops the LCD from swivelling and can cause your tripod locking mechanism problems though Manfrotto do give you the ability to overcome this with a locking nut you can adjust.

The sound monitor output is set to REC SOUND only when a micro HDMI or the YAGH is attached causing a small delay in the sound, this may be fixable in a future firmware upgrade. (This was explained in the video).

The rolling shutter is worse in 4K mode, this does not surprise me as the chip is at its outer limits of its own technology in order to deliver an internal 4K recordable image.

The GH4 is noisier in higher gain than my previous Canon C300, once again in my opinion you are asking a lot of the technology to record fantastic pictures at 4K without something suffering. I do realise the Sony A7s with its full frame sensor does exceed low light expectations but is flawed like the C500 by not recording 4K internally.

The micro 4/3 sensor is by its nature not as good as a full frame sensor for shallow depth of field but the inclusion of the 42.5mm f1.2 Leica lens is hard to beat.

Candy-web

Future features

As a video tool it would help if you could disable the back thumb wheel or have the ability to lock the shutter, the GH4 like it’s sister the GH3 is all buttons and wheels with your thumb hitting most of them at the least appropriate time.

I would like a smoother more responsive aperture, adjusting the exposure during a live production is a nightmare. Unlike a professional video lens the GH4 uses photographic lenses that are made for photography rather than video so racking up or down the aperture is very noticeable.

I would prefer some indication from the back of the camera that I was in record mode, how easy would it have been to add a front and back tally light to the YAGH.

A definite feature for the 10bit GH5″ must be a second SD card slot this would be very useful and the exclusion of the tiresome 30 minute record restriction.

With 2 SD card slots you could also copy your cameras picture profile allowing you to use it on a second “GH5″ saving a ton of set up time while using 2 cameras.

A major pain is the cameras lack of information during record mode, please stop the LCD information from timing out after 19 seconds in a firmware update.

Like all DSLRs the GH4 being no exception the lack of ND filters is a major pain during a sunny day especially as you want to keep your shutter to 1/50th of a second. Panasonic could take note by adding a slot behind the lens as was used in the 16mm Eclair during the 1980s.

HDW : These were scripted and recorded but not used as I decided it would extend the video beyond 20m and would make the back end rather boring.
